Overhead polyurethane insulation pipe

The working pipe and insulation layer are completely protected by the outer protective pipe, and can be used continuously for 30 years under normal working conditions.

Categories:

Contact Now

Product introduction
Galvanisedironinsulatedpipeconsistsofasteelpipeforconveyingmedium(workingpipe),apolyurethanerigidfoaminsulationlayer,andgalvanisediron(outerprotectivelayer).Itismainlyusedforoverheadpolyurethaneinsulationpipesandisprimarilyusedinliquidandgaspipelinenetworks,districtheatingnetworks,andmunicipalconstructionprojects.

Product features

(1)Insulationperformance

Thisproductusesapolyurethaneinsulationlayerstructure,effectivelyreducingheatloss.

(2)Easeofconstruction

Theinsulatedpipeisfactoryprefabricated,withbothendsexposedforalengthof150-250,makingitconvenientforalignmentandweldingduringon-siteconstruction.

(3)Weatherresistance

Theironusedfortheouterprotectivepipeiscoatedwithagalvanisedanti-corrosionlayer,allowingittoremaininoutdoorenvironmentsforextendedperiodswithoutcorroding.Asthisproductusesgalvanisedironinsteadofthetraditionalpolyethyleneouterprotectivepipe,itavoidstheissueofpolyethyleneageinginoutdoorenvironmentsovertime.Thegalvanisedironouterprotectivepipeadoptsaspiralformingstructure,whichoffersgoodoverallbendingperformanceandstressconditionsatthejointseams.

Specification and model
Specifications

（mm）

 Working steel pipe outer diameter

×wallthickness

(mm)

 Outerprotectivepipeouterdiameter

×wallthickness

(mm)

 Insulationlayerthickness

（mm）
25 32×3 100×0.5 33.5
32 38×3 110×0.5 35.5
40 45×3.5 110×0.5 32
40 48×3.5 110×0.5 30.5
50 57×3.5 125×0.5 33.5
50 60×3.5 125×0.5 32
70 76×4 140×0.5 31.5
80 89×4 160×0.5 35
100 108×4 200×0.5 45.5
100 114×4 200×0.5 42.5
125 133×4.5 225×0.5 45.5
125 140×4.5 225×0.5 42
150 159×5 250×0.5 45
150 165×4.5 250×0.5 42
200 219×6 305×0.8 42.2
250 273×6 355×0.8 40.2
300 325×7 405×0.8 39.2
350 377×7 485×0.8 53.2
400 426×7 530×1.0 51
450 478×7 580×1.0 50
500 529×8 635×1.0 52
600 630×8 740×1.0 54
700 720×9 825×1.2 51.3
800 820×10 930×1.2 53.8
900 920×12 1025×1.2 51.3
1000 1020×12 1127×1.2 52.3
1200 1220×14 1340×1.2 57.8
1400 1420×16 1570×1.5 73.5
1600 1620×18 1800×1.5 88.5

service life

Duetothethree-layerstructureofthisinsulatedpipe,theworkingpipeandinsulationlayerarefullyprotectedbytheouterprotectivepipe,allowingforcontinuoususefor30yearsundernormalworkingconditions.
